What is the concept of a wastewater treatment system?
A wastewater treatment system is a set of technologies that work together to meet unique wastewater treatment requirements.
Treatment of wastewater is rarely a static operation, and a wastewater treatment system that is designed to accommodate changes in treatment requirements can go a long way toward avoiding expensive replacements and improvements down the road.
What is typically removed by a wastewater treatment system?
A wastewater treatment system may include the technologies required to remove any of the following contaminants:
Biochemical oxygen demand
Nitrates and phosphates
Total suspended solids (organic and inorganic solid material)
Total dissolved solids (TDS) are any anions, cations, metals, minerals, or salts found in wastewater.
The Number of phases in the recovery process. These include:
(2) Straining and screening
(3) Addition of Chemicals
(4) Coagulation and Flocculation.
(5) Clarification and Sedimentation
(6) Filtration is the sixth step in the process.
(9) Finally, Distribution
How Wastewater Treatment Works
The Preliminary Treatment
As sewage reaches a wastewater treatment setup plant, it passes through a screen, which filters out large floating objects like rags and sticks that could clog pipes or cause equipment harm. After being screened, the sewage is guided to a grit chamber, where cinders, sand, and small stones settle to the floor. In communities with combined sewer systems, where sand or gravel can wash into sewers with storm water, a grit chamber is especially necessary. Sewage also includes organic and inorganic matter, as well as other suspended solids, after screening has been completed and grit has been extracted. Solid particles are microscopic particles that can be separated from sewage using a sedimentation tank. When the flow into one of these tanks is slowed, the suspended solids eventually fall to the bottom, forming a dense mass known as raw primary biosolids (formerly sludge). Pumping is typically used to drain biosolids from tanks, in which they are processed for use as fertilizer, disposed of in a landfill, or incinerated. Over time, primary treatment has proven insufficient to satisfy the demands of many societies for higher water quality. Cities and factories typically treat to a secondary treatment level to reach them, with specialized treatment used in some cases to eliminate nutrients and other contaminants.
By using the bacteria in the sewage, the secondary stage of treatment eliminates about 85 percent of the organic matter. The trickling filter and the activated sludge method are two of the most popular secondary treatment techniques. After the effluent exits the primary stage sedimentation tank, it flows or is pumped to a facility using one of these systems. A trickling filter is essentially a three to six-foot-deep bed of stones through which sewage flows. In trickling beds, interlocking bits of corrugated plastic or other synthetic media have recently been used. Bacteria colonize and multiply on these stones, eventually consuming the majority of the organic matter. The purified water is pumped out into pipes to be treated further. The partially filtered water flows from a trickling filter to a sedimentation tank to kill excess bacteria. The triggered sludge method, rather than trickling filters, is the current trend. By putting air and bacteria-laden sludge into close contact with sewage, the activated sludge process speeds up the bacteria's function. After leaving the primary stage's settling tank, the sewage is pumped into an aeration tank, where it is combined with air and bacteria-laden sludge and allowed to sit for several hours. The bacteria break down the organic matter into harmless by-products during this period. Returning the sludge to the aeration tank for mixing with air and fresh sewage would activate it once more with billions of bacteria and other tiny organisms. The partially treated water flows from the aeration tank to another sedimentation tank for bacteria removal. Before being discharged into receiving waters, effluent from the sedimentation tank is normally disinfected with chlorine to complete secondary care. To destroy pathogenic bacteria and eliminate odor, chlorine is added to the water. Chlorination can destroy more than 99 percent of the harmful bacteria in an effluent if done correctly. To prevent transporting and storing massive quantities of chlorine, which is sometimes in a gaseous state, some municipalities also produce chlorine solution on site. Dechlorination is a procedure that removes excess chlorine from wastewater until it is discharged into surface waters in many states. In cases where chlorine in treated water effluents can be toxic to fish and other marine organisms, alternatives to chlorine disinfection, such as ultraviolet light or ozone, are being used.
Some Treatment Options
Heavy metals, organic compounds, and poisonous chemicals, for example, are more difficult to extract from water today. The problem is only getting worse as demand for water rises. The growing need to reuse water necessitates improved wastewater treatment. Better methods of removing pollutants at treatment plants, as well as emission control at the source, are being used to address these issues. Pretreatment of toxic waste, for example, eliminates many problematic pollutants at the start of the pipeline rather than at the end. New approaches for eliminating contaminants are being created in order to restore more available water to receiving lakes and streams. Filtration, carbon adsorption, distillation, and reverse osmosis are only a few of the advanced waste treatment techniques currently in use or under development, which range from biological treatment capable of extracting nitrogen and phosphorus to physical-chemical separation techniques like filtration, carbon adsorption, distillation, and reverse osmosis. These wastewater treatment processes, whether used separately or in combination, can achieve almost any level of pollution control. Purified waste effluents may be used for commercial, agricultural, or recreational uses, as well as drinking water sources.
